Ceiling Grid吸頂型無塵室專用燈具  Ceiling Grid Suspended Cleanroom Luminaire
Ceiling Grid吸頂型無塵室專用燈具  Ceiling Grid Suspended Cleanroom Luminaire

Ceiling Grid吸頂型無塵室專用燈具 Ceiling Grid Suspended Cleanroom Luminaire

商品編號: C3

C3產品特色:

➊ 本產品適用2"T-GRID天花板及頂板為庫板之無塵室

➋ 燈具本體採用冷軋鋼板,無縫設計,滿焊接縫,不積塵,不洩漏,經酸洗處理,高級粉體烤漆,不生鏽,表面不起顆粒,不會造成汙染

➌ 內部含串接線,接線採公母接頭,施工時不需另外配管線

➍ 附T型吊鉤固定燈具,節省施工成本

C3型號選用說明

規格說明 電壓 燈管顏色 尺寸 (mm)

➀ T8 LED 2尺

➁ T8 LED 4尺

➂ T8 LED 5尺

➀ 100V

➁ 220V

➂ 277V

➀ 白色燈管

➁ 黃色燈管

➀ 623×50×70

➁ 1223×50×70

➂ 1523×50×70

C3 Features:

➊ This product is suitable for cleanrooms with 2" T-GRID ceilings and overhead plenum.

➋ The luminaire body is constructed from cold-rolled steel, featuring a seamless design with full welding seams. It is dust-resistant and leak-proof, treated with acid wash, and coated with high-quality powder paint that prevents rust. The surface is smooth, free of particles, and doesn't cause contamination.

➌ It comes with internal wiring, using male-female connectors, eliminating the need for additional conduit during installation.

➍ T-shaped hooks are included for securing the luminaire, reducing construction costs.

C3 Model Selection Guide:

Specifications Voltage Lamp Color Dimensions (mm)

➀ T8 LED 2 feet

➁ T8 LED 4 feet

➂ T8 LED 5 feet

➀ 100V

➁ 220V

➂ 277V

➀ White lamp

➁ Yellow lamp

➀ 623×50×70

➁ 1223×50×70

➂ 1523×50×70
